[envira-gallery id=”11932″] A&N have taken delivery of a brand new Haas VF4. X-Travel = 1270mm Y-Travel = 508mm Z-Travel = 635mm
Author Archives: Lukey2
27
Apr
Apr
Table Size = 660mm x 355mm (26″ x 14″) Machine Travels X = 508mm (20″) Machine Travels Y = 406mm (16″) Machine Travels Z = 508mm (20″)Table Capacity = 3000lb Equipped With: Haas 4th Axis Enabled Servo Haas 4th 210 Carousel 20 Station Tool Changer Chip auger Rigit Tap 61″]
26
Apr
Apr
Maximum Cutting diameter: 254mm Maximum Cutting Length: 500mm Bar Capacity: 51mm Through Hydraulic Chuck CNC Control: Siemans 840D Turret Positions: 8 Tool Station Chuck 1: 10″ 3 jaw Tailstock Options: Swarf conveyor Tool setter Tool Coolant Tailstock Collet Chuck Parts Catcher
25
Apr
Apr
Swing over bed: 470mm, (Swing between centers 730mm) Swing Over Cross Slide: 290mm Distance Between Centres: 1250mm Spindle bore: 80mm CNC Control: Prototrak LX2 Chuck 1: 10″ 3 jaw Chuck 2: 10″ 4 jaw Quick Change Toolpost with set of tool holders Tailstock. Options: Custom Made 200mm OD Tube Steady
